TH6000/S2 Injection Molding Machine

Parameters of TH6000/S2 Injection Molding Machine

Category: Extrusion Big Injection Weight Injection Molding Machine Injection Molding

TH6000/S2 injection molding machine adopts professional brand and is supplemented by precision hydraulic system and electrical system. Its product performance is stable, the operation of various projects is simple, energy saving and environmental protection (plasticizing screw, heating system, hydraulic motor, servo oil pump, etc.) cost and improve the market competitiveness of enterprises.

Add to quote

Details About TH6000/S2 Injection Molding Machine

Main features

Injection part: The machine occupies less land, saves plant land, reduces the length of the machine by 35%, and saves capital construction investment; the screw does not retreat, the aspect ratio is constant, the actual aspect ratio is constant, the process of raw material transportation remains unchanged, and the melt The material has no axial temperature difference, the plasticization quality has nothing to do with the product quality, the plasticization is good, and the back pressure is stable. The molding temperature is reduced, the product pressure is better, the internal pores are reduced, the surface quality is uniform, the product quality is good, and the large product quality is better; the injection precision is strong, no check ring design, no reverse material during injection, and injection weight repeatability is strong, Reliable sealing of plunger and valve core, long service life of high temperature seals, special sealing design, excellent sealing performance; low loss and maintenance-free, no screw head, non-return ring, sealing ring, very few wearing parts, and the same injection Compared with the ordinary machine screw, the diameter is greatly reduced, the disassembly is convenient, and the maintenance cost is low; the heating is fast, the power consumption is low, the heating device is arranged locally, the temperature rises quickly, the brand ceramic heating ring, 380V voltage design, high power density, long life ; Modular combination, the clamping part can be matched with injection parts arbitrarily to meet customer needs, and the installation position is reserved;clamping part: high rigidity clamping mechanism, strong self-locking ability to ensure minimal deformation of the template. The tie rod spacing is designed according to the standard mold base, and the versatility is good. The mold moving stroke is large, suitable for deep cavity products; the machining accuracy is strong, and the important parts such as the template machine glue are precisely machined by imported machine tools to ensure that the parallelism accuracy is far superior to the industry standard; the mold change, the template is equipped with a T-shaped slider, and the mold change efficiency Strong; strong load-bearing capacity of the formwork, hydraulic support for the moving formwork, effectively preventing the formwork from tilting forward, optional auxiliary support mechanism for the mold, suitable for the production of large-scale mud well molds; widened doors and windows, suitable for core-pulling molds, neat and beautiful, tempered glass , translucent and clean.

ITEMS

Units

TH6000/S2

INECTION  UNIT

Screw Diameter

mm

150

Screw L/D Ratio

 L/D

30

Piston diameter

mm

420

Shot Size(Theoretical)

cm3

454428

Injection Weight

g

331732

Injection Pressure

Mpa

129

CLAMPING  UNIT

Clamping Force

KN

60000

Clamping Stroke

mm

4700

Space Between Tie Bar

mm

2850×2500

Max. Mold Height

mm

4500

Min. Mold Height

mm

2000

Eject Stroke

mm

1200

Eject Force

KN

1100

OTHERS

Max. Pump Pressure

MPa

16

Pump Motor Power

KW

228/305.2

Heat power

KW

330

Hopper Capacity

Kg

400

Oil Tank Capacity

L

7000

Machine Weight

T

530
